Frequency Range

Freq.

10

52.000

MHz

Operating Temperature

T_use

-20

+70

℃

-30

+85

℃

-40

+85

℃

Storage Temperature Range

T_stg

-55

+125

℃

Supply Voltage

Vdd

1.7

3.3

V

Output Waveform

Clipped Sine Wave

Frequency Tolerence

Fo_tol

±2

ppm

T_use=25±2 ℃

Frequency Vs Temperature Change

Fo_Tc

±0.5

±2.5

ppm

T_use= -30℃～+85 ℃

Based on frequency at +25℃

Frequency vs Load Change

Fo_Load

±0.2

ppm

±10% load change

Frequency vs Voltage Change

Fo_Vdd

±0.2

ppm

Voltage varied ±5% at 25℃

Current Consumption

Icc

2

mA

Duty Cycle

SYM

40

60

%

Ground level

Output Level

Vp-p

0.8

V

Harmonics

-5.0

dBc

Output Load

Load

10KΩ//10pF

Start-up Time

T_str

2

mS

Phase Noise

-130

dBc/Hz

Offset:1KHz

-152

dBc/Hz

Offset:100KHz

Aging

f_age

±1

ppm

1st. Year at 25℃

±0.5ppm

±1.0ppm

±1.5ppm

±2.0ppm

±2.5ppm

-20℃ to +70℃

★

★

★

★

★

-30℃ to +85℃

★

★

★

★

★

-40℃ to +85℃

★

★

★

★

★

選擇需要的封裝規格及產品系列：   3.2×2.5mm；3T Series

選擇需要的頻率：    26.000MHz

選擇需要的工作電壓：   3.3V

選擇需要的輸出模式：   Clipped Sine Wave

選擇需要的頻率精度（at 25℃）：   ±1ppm

選擇需要的工作溫度范圍：    -40℃~+85℃

選擇需要的頻率&溫度特性：  ±0.5ppm

您需要的產品是： 3T Series 26.000MHz 3.3V Clipped Sine Wave ±1ppm@25℃ ±0.5ppm@-40~+85℃
